Cobalt chromium alloy ASTM F1058 phynox elgiloy

  • Cobalt chromium alloy ASTM F1058 phynox elgiloy
  • Cobalt chromium alloy ASTM F1058 phynox elgiloy
  • Cobalt chromium alloy ASTM F1058 phynox elgiloy
  • Cobalt chromium alloy ASTM F1058 phynox elgiloy
  • Cobalt chromium alloy ASTM F1058 phynox elgiloy
Model No.︰ASTM F1058
Brand Name︰xagy
Country of Origin︰China
Unit Price︰US $ 167 / Kg
Minimum Order︰1 Kg
Share on:

 Total 20 Related Items
Prev34567Next

Product Description

Description

This Cobalt-Chromium-Nickel alloy gives a combination of high strength, ductility and good mechanical properties and is age hardenable. elgiloy also has excellent fatigue life, corrosion resistance in numerous environments and is non-magnetic. it has high corrosion resistance and low relaxation stress at  the height of 600 F.

Commerical Trade Name  Elgiloy Alloy
Material  Cobalt Chromium alloy
Standard Specification ASTM F1058
Surface Finish Cold-finish
TOL.Thick. ±0.03mm
TOL.Width ±0.2mm
Final weight Tolerance ±10% (Custom-Made Order)  ,±0.2Kg ( Stock Available)
I.D. Value 200-500mm (Paper Coil I.D.)
O.D. Value Base on COLD WEIGHT
Country of origin China, Xi'an

Forms of supply

ROD Dia.20 to 280mm,Length3000mm,Max Surface Finish: Black, De-scaling & Ground Surface
STRIP T0.1 to 3.0mm ,width300mm,Max Temper Name : Hard / Annealed
PLATE T3.0 to 40.0mm,Width1000mm,Max Surface Finish: Black / Bright

Product Datasheet

TABLE 1   Chemical Compostition,%
C Mn Si P S Be Cr Ni Co Mo Fe
0.15,Max 1.5-2.5 1.2,Max 0.015,Max 0.015,Max 0.1,Max 19.0-21.0 14.0-16.0 39.0-41.0 6.0-8.0 Bal.









TABLE 2   Physical Properties
Density, g/cm3 8.3
Shear modulus,G/MPa 73500-83500
Magnetic Rate,K/106  50-1000
Thermal Expansion ,20-100ºC/(10-6/K) 14
Modulus of elasticity,MPa 196000-215500
Resistivity,p/(μΩ•m) 0.92



TABLE 3   Mechanical Properties
Forms Condition Size/mm Tensile Strength ób/MPa Elongation ó(%)≥
Strip Cold-Rolling 0.1 to 2.5 1150 to 1895 3
Wire Cold-Drawing 0.2 to 3.5 1515 to 1795 ...



REMARK:

SPECIFICATION: ASTM F1058-08

1. Mechanical Property can be improve with Cold Worked & Aged

2. Rod forms fully compliance with chemical component

3. Annealed possible for wire & Strip



About Us

XI'AN GANGYAN SPECIAL ALLOY CORPORATION (XAGY)
Specialized in manufacturing Nickel alloys & Cobalt alloys for 25+ years,with a company mission to provide a high quality, reliable source for precision alloys, high temperature alloys and stainless steels in both pilot processing and mass production. We are professionally manufacturing materials with unique features, which are then used in aerospace, military, electronics, marine, petroleum and petrochemical industries. Now our company has formally marketed in China's new stock market, stock No. 836660.

Base on "Quality-oriented, Leading Technology, Continuous Improvement, Customer Satisfaction", we believe XAGY Inc can be your best supplier.

Warehouse

Alloy raw materials Like Cobalt, Nickel ,Chromium & ETC.are purchased from large-scale state-owned company, quality assurance, storage capacity up to 200 tons -300 tons, guaranteed enough regular size products in stock . Using ERP system to manage the inventory.product availability and request a QUOTE!

Certificate

ISO9001 Approved Since 2005

Mill Certificate & Rohs report with goods

Quality Contral

The Quality control team has 18 members, mainly responsible for the analysis and detection of all raw materials and finished products in the factory, analysis and testing items such as physics, chemistry, materials, mechanics, appearance and dimensions ,etc.

Exhibition(2018)

EMC ShangHai (China)Every Year , Shanghai city

Metal Week (Korea) Every Year, Seoul City

Wire Dusseldorf (Germany)Wire Dusseldorf (Germany)

Important Notice

1. Material Specification

Chemical composition,Physical and Mechanical properties will be engineered according to specific customer requirements.Therefore chemical composition,physical and mechanical properties might be different to values listed in this document.


Information about product characteristics or applicability of materials are shown only for informative purposes.

2. Sample Policy

Elgiloy Alloy are available in many shapes and dimensions,supplying semi-finished products in forms of Strip,plate & Rods.The samples are big enough (typically about 200mm in length for strip or plate) to get an understanding of the material characteristics, meanwhile custom-made sample order available ! small quantity accepted.

3. Payment Terms

30% T/T in advance ,balance before shippment.

4. Who you talking to

Mr. Paul (Designation :Foreign Trade Manager)
WeChat & Phone No: +86 (0)13669288752 (24 Hours)
Skype: alloynickel
Tel: +86 29 3366 9103 ( 08:30-17:30,Beijing Time. Mr.Paul ,Excellent Engilsh & Mandarin)
Fax: +86 29 3369 8670
Email: supportsales©xagy.cn
Http:// www.alloynickel.com

Payment Terms︰T/T
